Scaphoid Fracture

A scaphoid fracture after a fall onto an outstretched hand can be occult on initial radiographs; immobilise clinical suspicion, obtain definitive imaging promptly, and escalate proximal or displaced injuries because retrograde blood supply makes non-union and avascular necrosis clinically important.

In a nutshell

Suspect a scaphoid fracture after a forced-hyperextension injury with focal scaphoid tenderness. Initial radiographs may be normal: immobilise and arrange definitive imaging. The proximal pole and displaced fractures need urgent specialist assessment because retrograde blood supply increases the risk of non-union and avascular necrosis.

Classic presentation

A patient with thumb-side wrist pain and anatomical snuffbox tenderness after a fall onto an outstretched hand, with a normal or equivocal initial radiograph.

Key points

  • Examine the anatomical snuffbox, scaphoid tubercle and proximal pole, and assess pain on ulnar deviation and axial thumb loading.
  • Request dedicated scaphoid radiographs, but do not use a normal initial film to exclude the fracture.
  • Immobilise a clinically suspected fracture and arrange MRI or specialist review; NICE supports MRI as first-line imaging after thorough examination.
  • Use CT to measure displacement in a definite fracture and to assess union when radiographs are equivocal or symptoms persist.
  • Stable, minimally displaced waist or distal-pole fractures can be casted under specialist follow-up; displaced, unstable and proximal-pole injuries need urgent hand or orthopaedic assessment.
  • Do not end follow-up just because pain improves: union needs appropriate radiographic or CT confirmation.

First-line investigation

Thorough wrist examination followed by dedicated scaphoid radiographs; if the films are normal or equivocal but suspicion remains, arrange MRI through the urgent specialist pathway.

Management

Protect and image

  • Assess skin and neurovascular status, immobilise the wrist, obtain dedicated scaphoid radiographs and give analgesia using the current BNF and local trauma protocol.1,4

Do not dismiss a normal film

  • If suspicion persists despite normal or equivocal radiographs, keep the wrist immobilised and arrange MRI or specialist review; NICE supports MRI as first-line imaging after thorough examination.3,1

Stratify the fracture

  • Use CT for displacement in a definite fracture. Stable minimally displaced waist or distal-pole injuries may be casted, whereas displaced, unstable or proximal-pole injuries require urgent specialist assessment and may need fixation.1

Prove union

  • Arrange union imaging at the specialist-recommended interval; persistent tenderness, absent progression or cystic change requires CT and reassessment for continued immobilisation or surgery.1

Protect recovery

  • Give cast or splint care, activity and analgesia advice, and return instructions for worsening pain, numbness, colour change or cast problems; later recurrent wrist pain also needs review because non-union can present after the initial injury.1,2,4

Exam traps

  • A normal initial X-ray does not exclude a scaphoid fracture.
  • The proximal pole is higher risk for avascular necrosis because its blood supply is predominantly retrograde.
  • A definite fracture needs CT assessment of displacement; do not classify management from a single plain view alone.
  • Displaced proximal-pole fractures are an urgent specialist problem, not routine cast follow-up.
  • Persistent tenderness or a fracture gap during follow-up suggests delayed union or non-union and needs CT or specialist review.

Illustrations

Anatomical snuffboxPhotograph illustrating the borders and palpation point of the anatomical snuffbox on the radial wrist.Kayawaya, Wikimedia Commons · CC0
Retrograde blood supply of the scaphoidDiagram showing the radial artery branches entering at the distal pole and supplying the proximal pole retrogradely.PassFinals · original
X-ray of a scaphoid waist fractureRadiograph demonstrating a fracture line across the waist of the scaphoid.James Heilman, MD, Wikimedia Commons · CC-BY-SA-4.0

Key sources

  1. British Society for Surgery of the Hand: Scaphoid fracture standards of care (Current BSSH acute scaphoid fracture standard for adults over 16, covering dedicated radiographs, immobilisation, MRI or CT pathways, displacement and proximal-pole referral, fixation and union follow-up; document to be revised in 2027.)
  2. Cambridge University Hospitals NHS Foundation Trust: Scaphoid fractures (NHS patient information on occult presentation, immobilisation, follow-up imaging and recovery advice for scaphoid fractures.)
  3. NICE NG38: Fractures (non-complex): assessment and management (Recommendation 1.2.3: consider MRI for first-line imaging in people with suspected scaphoid fractures after a thorough clinical examination; guideline last reviewed 23 June 2025.)
  4. BNF online: current analgesia prescribing information (Use the current BNF and local trauma protocol for age-, weight-, renal-function- and pregnancy-appropriate analgesic choice, dose, contraindications and monitoring; no fixed dose is reproduced here.)
